Safety quarter turns for railway
Safety quarter turn version railway with marking, Stainless steel AISI 304; 1000-SU821
with stainless steel nut
Safety quarter turn square 6, Stainless steel AISI 316; 1000-U817-01PH
with stainless steel nut
Safety quarter turn square 8, Zinc die chrome-plated; 1000-U817-03IA
with earthing nut
Safety quarter turn square 8, Stainless steel AISI 316; 1000-U817-03PH
with stainless steel nut
Safety quarter turn triangular 8, Stainless steel AISI 316; 1000-U817-05PH
with stainless steel nut
Safety quarter turn with slot 1.2 x 3, Zinc die chrome-plated; 1000-U817-16IA
with earthing nut
Safety quarter turn hexagon female SW 8, Stainless steel AISI 316; 1000-U817-24PH
with stainless steel nut
Safety quarter turn triangular 8 with marking, Stainless steel AISI 316; 1000-SU51
with stainless steel nut
Safety quarter turn version railway with optical opening indicator and marking, left version, Stainless steel AISI 316; 1000-SU610-LI
with nut and additional locking screw
Safety quarter turn version railway with optical opening indicator and marking, right version, Stainless steel AISI 316; 1000-SU610-RE
with nut and additional locking screw
Safety quarter turn railway version, Stainless steel AISI 303; 1000-U710-01
with stainless steel nut
Safety quarter turn railway version, Brass and stainless steel black powder-coated; 1000-U732-01
with earthing nut
Safety quarter turn railway version, Brass and stainless steel chrome-plated; 1000-U733-01
with earthing nut
Safety quarter turn square 7, Zinc die chrome-plated; 1000-U817-02IA
with earthing nut
Safety quarter turn triangular 7, Zinc die chrome-plated; 1000-U817-04IA
with earthing nut
Safety quarter turn triangular 8, Zinc die chrome-plated; 1000-U817-05IA
with earthing nut
Safety quarter turn triangular 10, Stainless steel AISI 316; 1000-U817-07PH
with stainless steel nut
Safety quarter turn double bit 3, Zinc die chrome-plated; 1000-U817-08IA
with earthing nut
Safety quarter turn slot 2 x 4, Zinc die chrome-plated; 1000-U817-17IA
with earthing nut
Safety quarter turn railway version, Zinc die chrome-plated; 1000-U817-23IA
with earthing nut
