Insert part square 8 with thread M6 for wing knob, Zinc die zinc-plated
Blind plug, Zinc die black powder-coated
Product Benefits:
- Kostenersparnis durch sekundenschnelle, werkzeuglose Montage
- leichtgängige Bedienung (konzeptbedingt keine innere Verspannung)
- Rastzunge mit Sicherungs-Kappe
- selbstdichtender Aufbau für höchste Schutzansprüche (konzeptbedingt)
- hohe Überdrehsicherheit
- Standardlochbild
- patentgeschützt
Product information:
A = Montage: Beispiel rechter AnschlagB = Demontage
Internal Reference:
1000-U913
Standards:
Protection class IP 65
Barcode:
1000-U00913-0000000
Product Type:
Quarter turn
Program:
1000
Catalog sheet:
1B-170
Material of the module :
Zinc die
Surface of the module:
zinc-plated
Number of Possible Locking Points:
1 point
Article with property rights:
Yes
Fixing type of housing :
clamp-on / clip fix
Mounting Positions :
Inside the sealing
Housing Head Shape:
Square
Housing Head Size:
33 x 55 x 5 mm
Suitable for door thickness from:
1 mm
Suitable for door thicknesses up to:
3 mm
Locking set:
Insert
Locking components:
Cam
Quarter turn types:
Quarter turn with simple insert,Quarter turn for assembly without tools
No Specifications
No Matching Products
Here you can find the product data sheets and CAD files of this product
