Product Benefits:
Features:
Simple assembly!
Assembly instruction:
Easy to assemble by using clip fix plastic parts.
Internal Reference:
1000-U350
Product Type:
Quarter turn
Program:
1000
Catalog sheet:
1B-760
Material of the module :
Polyamide GF
Surface of the module:
pebble grey
Number of Possible Locking Points:
1 point
Fixing type of housing :
clip-in
Mounting Positions :
Inside the sealing
Housing Head Shape:
Round
GH Mass:
28 mm
Handle Art:
Wing knob
Suitable for door thickness from:
1 mm
Suitable for door thicknesses up to:
1.25 mm
Locking set:
No locking set, blind
Door Version :
Left,Right
Locking components:
Cam
Quarter turn types:
Quarter turn with handle
No Specifications
No Matching Products
Here you can find the product data sheets and CAD files of this product
