Flat rod with double roller for catch with catch bracket and extended catch area, Steel black; 1121-U161-01
Product information:
② = Flat rod with double roller for catch with catch bracket
③ = Catch bracket
④ = Rod guide
Internal Reference:
1121-U161-01
Product Type:
Rod
Program:
1121
Catalog sheet:
3ZA-1210
Material of the module :
Steel
Surface of the module:
black
Connecting rod position:
Outside the sealing, top or bottom
Number of Possible Locking Points:
2 points
C Dimension:
275
D Dimension:
700
Mounting Positions :
Outside the sealing
Flat Bar Outside:
Flat rod with double roller
For Door Height:
1600-1900
X-Dimension:
101.5
Y-Dimension:
526.5
