180° Hinge, Steel zinc-plated
180° Hinge, Steel zinc-plated
180° Hinge, Steel zinc-plated
180° Hinge, Steel zinc-plated

180° Hinge, Steel zinc-plated black; 1039-U12-JD

https://www.emka.com/products/1039-u12-jd-180-hinge-steel-zinc-plated-black-61310 https://www.emka.com/web/image/product.template/61310/image_1920?unique=ffc2011

    This combination does not exist.

    Single cabinets Left Right
    Internal Reference: 1039-U12-JD
    Barcode: 1039-U00012-00000JD
    Product Type: Hinge
    Program: 1039
    Surface: zinc-plated black
    Material of the module : Steel
    Surface of the module: zinc-plated black
    Door return variable: Yes
    Execution: three-piece
    Type of attachment to the frame: screw-on from inside
    Type of fastening on the door: screw-on from inside
    Hole pattern required in the door: Bore holes in the door
    Max. opening angle due to installation: Yes
    Max Opening Angle: 180°
    Cabinet type : Single cabinets
    Door position: prominent
    Door Version : Left,Right
    Captive pen: Yes
    Cannot be disassembled from the outside: Yes
