Profile hinge, screw-on, Steel zinc-plated
Hinge, Zinc die black powder-coated
Product information:
In case of 18 mm, an opening angle of 180° for in-line cabinets with double doors is possible.
Internal Reference:
1036-U9
Product Type:
Hinge
Program:
1036
Catalog sheet:
4A-295
Material of the module :
Zinc die
Surface of the module:
chrome-plated
Dimension A, Variable:
18 - 23.5 mm
Door return variable:
Yes
Detachable:
without tools
Type of attachment to the frame:
screw-on from inside
Type of fastening on the door:
screw-on from inside
Hole pattern required in the door:
Bore holes in the door
Max Opening Angle:
180°
Cabinet type :
Single cabinets,In-line cabinets with single door,In-line cabinets with double door
Door position:
prominent
Door Version :
Left,Right
Captive pen:
Yes
No Specifications
No Matching Products
Here you can find the product data sheets and CAD files of this product
