Round rod L = 551 - 600 mm, Steel zinc-plated
Round rod L = 651 - 700 mm, Steel zinc-plated
Order / Calculation example:
Order number for a round rod with eye, tapered end and a length of 1034 mm = 1000-211-L 1034
Internal Reference:
1000-211-06
Product Type:
Rod
Material:
Steel
Program:
1000
Surface:
zinc-plated
Connecting rod position:
Inside the sealing, top or bottom
Number of Possible Locking Points:
2 points, 3 point
Mounting Positions :
Inside the sealing
Dimension L up to:
650 mm
Dimension L from:
601 mm
Length(L-dimension):
601 - 650 mm
Round bar inside the seal:
Round rod with cone and eye
No Specifications
View All Products
Here you can find the product data sheets and CAD files of this product
